PVC INSULATED RUBBER TAPE
PVC INSULATION/ELECTRIC RUBBER TAPE
Item No.: JMV-PIRT-01
Name: PVC Insulation Tape
Material: PVC
Application: LOW VOLTAGE
Rated Voltage: 600V
Tensile Strength: ≥20
Color: red,yellow,black,brown,Violet, etc.
Adhesive: Rubber
Use: Electrical Insulation
Feature: Heat-Resistant
Material: PVC
Application: LOW VOLTAGE
Rated Voltage: 600V
Tensile Strength: ≥20
Color: red,yellow,black,brown,Violet, etc.
Adhesive: Rubber
Use: Electrical Insulation
Feature: Heat-Resistant
Description
PVC electric tape is made from heavy duty, industrial grade PVC. It is flame retardant, resistant to acids, alkalis, UV, oil, abrasion, and moisture.
It have a sticky rubber resin that offers superior adhesive qualities.
Specification:
It have a sticky rubber resin that offers superior adhesive qualities.
Specification:
| Model No | 120C | 130C | 150C | 165C | 180C | 190C | 200C |
| Total thickness(um) | 120 | 130 | 150 | 165 | 180 | 190 | 200 |
| Carrier | PVC film | PVC film | PVC film | PVC film | PVC film | PVC film | PVC film |
| Tensile strength(N/cm) | 16 | 18 | 20 | 21 | 22 | 23 | 23 |
| Elongation% | 180 | 200 | 220 | 220 | 220 | 220 | 220 |
| Adhesive strength to steel(N/cm) | 1.5 | 1.8 | 1.8 | 1.8 | 1.8 | 1.8 | 1.8 |
| Adhesive strength to backing(N/cm) | --- | --- | --- | --- | --- | --- | --- |
| Dielectric strength(kv/mm) | 35 | 35 | 35 | 35 | 35 | 35 | 35 |
| Accord with Rohs and Reach | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| Max Temperature℃ | 80 | 80 | 80 | 80 | 80 | 80 | 80 |
